VW Volkswagen Crafter TDI Fuel Injector Bracket Clamp Jaw Holder 04L130216A

The VW Volkswagen Crafter Fuel Injector Mounting Bracket TDI is an item from the Injector Nozzles category, designed for securely mounting the injector in a TDI diesel engine. Proper injector mounting is crucial for precise fuel delivery, the smooth operation of the power unit, and the durability of the entire system.

Specifications and technical data

• SKU: 04L130216A
• Mark: Volkswagen
• Condition: Used
• OEM Part Number: 04L130216A
• Substitutable numbers: 04L130216A, 04L 130 216 A
• Part type: Fuel Injector
• Category: Fuel Injectors

Purpose and Function of the Injector Bracket

The TDI fuel injector mounting bracket in the Volkswagen Crafter is responsible for rigidly and axially holding the injector in the engine head. A correctly selected and functional component:

• stabilizes the injector's position relative to the combustion chamber, promoting uniform fuel atomization,
• reduces injector vibrations and micro-movements, minimizing the risk of leaks at the seat,
• supports maintaining the correct clamping pressure on the sealing washers,
• reduces mechanical loads acting on the injector body during engine operation.

This ensures the entire injection system operates more smoothly, resulting in stable engine performance, correct emissions, and predictable vehicle behavior under load.

Compatibility with TDI Injection System

The offered bracket is a dedicated component for use in TDI engines fitted in the Volkswagen Crafter model. Using a part from the Volkswagen OE group allows for maintaining factory installation parameters, such as:

• correct mounting geometry relative to the injector seat,
• proper sealing surface ensuring a leak-free connection,
• compatibility with original screws and accessories of the injection system.

Selecting a bracket that matches the factory specification minimizes the risk of installation problems, injector misalignment, or accelerated wear of the head seats.

Characteristics of a Used Part

The presented bracket comes from the secondary market, meaning it is a used part. Such components, provided they retain their correct geometry and have no structural damage, can be successfully reused in a vehicle, offering a sensible compromise between cost and functionality.

For injector mounting components, it is essential that:

• mating surfaces are flat and allow for proper clamping,
• injector guiding areas retain their shape ensuring axial alignment,
• there are no cracks or deformations affecting mounting safety.

Prior to installation, a standard visual inspection and cleaning of the component from operational deposits are recommended to facilitate proper injector seating.

Importance of Correct Mounting for Engine Operation

In TDI diesel engines, the precision of injector positioning directly impacts:

• fuel atomization quality and spray pattern in the combustion chamber,
• uniform operation of individual cylinders,
• noise and vibration levels generated by the power unit,
• emissions and fuel consumption.

Incorrect mounting can lead to exhaust blow-by at the seat, carbon buildup, and consequently, damage to the injector or cylinder head. If you want to better understand the symptoms that may indicate problems with the injection system, it is worth reading the article Diesel Injector Faults – How to Recognize Them and What Their Neglect Entails.

Other Volkswagen Injector Nozzles

If you are assembling the injection system or planning a more extensive service for your Crafter, you may also need other components from the same group. Check the available Volkswagen injector nozzles to select other components that comply with the manufacturer's factory requirements.
